Hfree dies hydraulic PLC control dished end flanging machine 70
Dished end machine is used to forming the dish head with dished spinning machine. Dish end forming and flanging machine can produce various kinds of dished ends, such as ellipse, dish, taper, and sphericity.
Dished end machine consists of a forming machine, a flanging machine, and an edge trimmer machine. Besides, the spinning speed is adjusted, and hydraulic press forming makes it easier to operate.
Hfree dies hydraulic PLC control dished end flanging machine 70 characteristics
Hfree dies hydraulic PLC control dished end flanging machine is the second step for steel dishes tank ends. Adopting spinning principle, this machine will make blank workpiece from drum machine into ellipse end, dish end, sphericity end. Flat-bottom or taper-bottom end, tec.
The structure is closed frame type, good rigidity. The spinning speed is stepless adjusted.And PLC control(Omron from Japan) makes operation easier.
Different diameter and thickness technical data.
Modle | Max. thickness(mm) | Max.length(mm) | Advantages | Voltage(V) |
Jy1020 | 10 | 2000 |
the dished end have smoothly surface, less wheel marks, good roundness, Less thinning and ,high productivity |
380V/50HZ/3phase
220V/60HZ/3phase |
Jy1040 | 10 | 4000 | ||
Jy10100 | 10 | 10000 | ||
Jy2060 | 20 | 6000 | ||
Jy20100 | 20 | 10000 | ||
Jy3040 | 30 | 4000 | ||
Jy3080 | 30 | 8000 | ||
Jy30100 | 30 | 10000 | ||
Jy4060 | 40 | 6000 | ||
Jy4080 | 40 | 8000 | ||
Jy40100 | 40 | 10000 | ||
Jy5060 | 50 | 6000 | ||
Jy5080 | 50 | 8000 | ||
Jy50100 | 50 | 10000 |
 |  |
